BMW N42/N46 Timing / Cam Carrier & Plier Kit

DM11-B1156

Camshaft timing tool for checking and adjusting both the vanos and locking camshafts on petrol engines.

Models: E81/ E82/ E87 118i / 120i (04 - 09)
              E46 316i / 316ti / 318i / 318ti (01 - 07)
              E90/ E91/ E92/ E93 318i / 320i (05 - 09)
              E60 520i (04 - 08)
              E85 / E86 Z4 (04 - 09)
              E83 X3 2.0i (05 - 09)
              E83 X3 2.0i (01 - 10)

Engines: N42 / N46 / N46N / N46T

OEM: 119340 / 113350 / 119292 / 119291 / 115120 / 119270 / 119293 / 119190 / 119 340 / 113 350 / 119 292 / 119 291 / 115 120 / 119 270 / 119 293 / 119 190

DM11-C1156

When taking camshafts out of the head this kit is used to correctly install the variable Inlet camshaft back in the cylinder head.

Models: E46 / E60 / E83 / E85 / E87 / E90 / E91

Engines: N42 / N46 (B18 / B20)

OEM: 119301 / 119302 / 119303 / 119310 / 119320 / 119390 / 119 301 / 119 302/ 119 303 / 119 310 / 119320 / 119 390

DM11-A1156-12

For removal and installation of the Valvetronic tension springs.This BMW engine tool is vital when removing and installing the loaded spring clips on the rocker gear on the camshaft.

Before removing the spring, fix the BMW N42 and N46 Spring Removal and Installation Pliers on the position plate and loosen the bolt.
Open the BMW N42 and N46 Spring Removal and Installation Pliers carefully, unload the spring and take it off.
Close the BMW N42 and N46 Spring Removal and Installation Pliers to tighten the spring while installing it.
Match the bolt to hole, and lock.

Engines: N42 / N46

OEM: 119 390 / 119390
